2-288 Core Direct Burial or Duct Single Mode Fiber Optic Cable details: Fiber optic cable / Fiber cable / Optic cable /
Description
Basic Info.
| Model NO. | Single Mode Fiber Optic Cable |
| Core | Double Core |
| Certification | RoHS, ISO9001, Single Mode Fiber Optic Cable |
| Brand | OEM or Tw-Scie |
| Sheath Material | LSZH,HDPE,MDPE |
| Loose Tube Material& Filling Material | PBT&Jerry |
| Brand Name of Fiber | Corning, Yofc, Draka,..as Requiremen |
| Central Strength Member | Reinforced Messenger Wire |
| Color of Loose Tube | Blue,Orange, Green, Brown etc |
| Fiber Account | 2-288 Core |
| Armour Material | Steel Armour |
| Jacket Material | MDPE /HDPE/ LSZH |
| Model No | GYTY53 Single Mode Fiber Optic Cable |
| Transport Package | Wooden Drum |
| Specification | ISO, ROHS, REACH, SGS |
| Trademark | TW-SCIE or OEM |
| Origin | China (Mainland) Guangdong Dongguan |
| HS Code | 8544700000 |
| Production Capacity | 150km/Day |
Product Description
Fiber optic cable / Fiber cable / Optic cable / Optic fiber cable / Optical cable / Fiber optic
Application:
These corrugated steel tape armored and double sheath cables are suitable for installation in harsh environments where mechanical impact on the cable to be expected, e. G. Direct buried application. They are also suitable for installation in ducts where the rodent resistance is to be expected.
Features:
1. Up to 288 fibers
2. The loose tube stranding technology make the fibers have good secondary excess length and allow the fibers free movement in the tube which keeps the fiber stress-free while the cable is subjected to longitudinal stress.
3. Corrugated steel tape armored and double PE sheath providing excellent crush resistance and rodent resistance.
4. Metal strength member provides excellent strain performance.
| Technical data: | ||||||||
| Fiber Num. | Outer diameter (mm) | Weight (kg/km) | Min.Bending radius(mm) | Tension (N) | Crash loading (N/100mm) | |||
| Static | Dynamic | Short term | Long term | Short term | Long term | |||
| 2-24 | 12.6 | 185 | 12.5 times O.D. | 25 times O.D. | 3000 | 1000 | 3000 | 1000 |
| 26-36 | 12.9 | 195 | ||||||
| 38-60 | 13.4 | 200 | ||||||
| 62-72 | 13.9 | 230 | ||||||
| 74-96 | 15.5 | 275 | ||||||
| 98-120 | 17 | 320 | ||||||
| 122-144 | 18.4 | 365 | ||||||
| 146-216 | 18.9 | 385 | ||||||
| 218-240 | 22.1 | 495 | ||||||
| 242-288 | 24.3 | 580 | ||||||
Our Quality & Service:
DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:
1.Consistently meeting for product quality and performance;
2. Timely delivery of products and services to meet our customer's requirements;
3. Ensuring that our people are properly trained so that they are better able to serve our customers.
Our Certificate:
REACH
ROHS
TLC Telecom Certificate
Environmental Management System Certification
ISO9001:2000
Utility Model Patent Certificate
Please feel free to contact with us for cooperation and excellent service.
