China FTTH 2/4/6/8/12/16/24 Core MPO/MTP LC/Sc/St/FC/Mu E2K Connector Indoor Outdoor Armoured Drop LSZH PVC Fiber Optic Optical Patch Cord Pigtail Jumper Cable

Basic Info.

Model NO.	MPO/MTP LC/SC/ST/FC
Connection Structure	MPO/MTP
Material Shape	Ribbon Cable, Mini Round Cable
Allowed Lateral Pressure	100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength	100N<1000N
Core	Multicore
Certification	RoHS, ISO9001
Brand	ODM
Sheath Material	PVC.LSZH
IEC 61754-7 Compliant	Compact Design, up to 24 Fiber Ribbon
Cable Jacket Color	Blue,Green,Aqua,Red,Magenta,Beige
Adapter Type	MPO
Channel	2 /4/6/8/10/12/16/ 24
Housing Color	Aqua,Green, Beige,Yellow, Magenta
Boot Color	Black
Boot Type	Round, Flat
Polishing	APC, PC
Cable Jacket Material	PVC, LSZH, Ofnr, Ofnp, PE
Hybrid Connector	LC/FC/Sc/St
Cable Type	Round/Ribbon
Cable Diameter	3.0mm/4.5m/6.0mm
Fanout Length	0.5m/1m/2m
Transport Package	Single Pack
Specification	CE, RoSH, SGS
Trademark	KOC
Origin	Made in Shenzhen China
HS Code	85447000
Production Capacity	500/Prt Month

Product Description

China FTTH 2/4/6/8/12/16/24 Core MPO/MTP LC/Sc/St/FC/Mu E2K Connector Indoor Outdoor Armoured Drop LSZH PVC Fiber Optic Optical Patch Cord Pigtail Jumper Cable

MPO Optical Patch-Cord

Note: The price range is for MPO(female)-MPO(female) Multimode 24 core mini round cable 1m. With 21 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website kocchina.en.made-in-china.com. In case of need, please do not hesitate in contacting us.

SPECIFICATIONS

	Single mode	Multimode
Insertion Loss	Low Los ≤ 0.35dB	Low Los ≤ 0.35dB
Insertion Loss	Standard Loss ≤ 0.7dB	Standard Loss ≤ 0.5dB
Return Loss	≥ 55dB	≥ 30dB
Durability	<0.3dB typical change, 200 matings	-
Operating Temperature	-40 to +85 ºC	-40 to +85 ºC

KOC MPO solution is designed for high-density fber connections and high-speed data center cabling. We provide an economic highly reliable solution for your fber network systems.
APPLICATIONS: - CATV, and Multimedia - Gigabit Ethernet - Industrial and medical - Active device interface - Premise installations - Interconnection for O/E modules - Data processing networks - Telecommunication networks - Optical switch interframe connection - Asynchronous Transmission Mode (ATM)

FEATURES:

- IEC 61754-7 Compliant

- Compact design, up to 24 fiber ribbon

- Polishing does not require diamond film

- Precision molded MT ferrule

- Telcordia GR-1435-CORE compliant

- Low insertion loss and back reflection loss

- High precision guide pins for exact alignment
